产品概况:
Single Mode Fiber Coupled Laser Diode is the
most competitive product of WAVESPECTRUM.
We offer High Coupling Efficient Solution for
405nm~1650nm Pigtailed Laser Module with
Single Mode Fiber and Polarization Maintianing
Fiber, the output power can be up to 100mW.
We adopt unique technique to get high
Polarization Extinction Ratio (PER), wihch
is up to 20dB with Low Noise Laser Output.
With SM and PM Fiber, it can get the Gauss
Beam which is the Single Transverse Mode
Beam and the M2 value is less 1.3. Meanwhile,
the TE Cooler and Photodiode is optional for
customers, we can integrate them into the Laser
Moudue according to customer's requirement.
WAVESPECTRUM also offer the Customized Solution
for Pigtailed Laser Modules, such as Customized
Wavelength and Customized Power to meet the special
needs of customers.
产品特征:
405nm~1650nm SM and PM Fiber
1mW~100mW Output Power
PER upto 20dB
Built-in TE Cooler Optional
Built-in Photodiode Optional
Long Lifetime;High Stability
Customized Wavelength
Customized Output Power
